Physical Dimension

mm

9422 X 2250 X 2100

Rated Loading Capacity

KG

25000

Vehicle Weight Without Load

KG

28600

Rated Power/RPM

KW/RPM

200/2000

Driving Method

4 X 4 Full Wheel Drive

Transmission Method

Hydraulic

Starting Method

Air Starting

Climbing Capacity

Longitudinal: 14

Transverse: 7.5

Max Pulling Force

KN

220

Pulling Force of Draw-work

KN

120

Min Ground Clearance

mm

320

Min Rotating Radius

mm

Int: 3700

Ext: 6400

Travelling Speed (Dry Hard Road)

KM/h

No load:24

Full Load:22.5

Wheel Base

mm

3200

Track Width

mm

1550
